自動變速箱故障現象：自動變速器出現升檔緩慢，發動機轉速達4000r/min才能升檔，升檔時沖擊大的現象。

Automatic transmission malfunction phenomenon: The automatic transmission experiences slow upshifting, with the engine speed reaching 4000r/min before upshifting, resulting in significant impact during upshifting.

自動變速箱故障分析：技師檢查自動變速器油(ATF)，發現油量正常，無異味。根據現象判斷，是發動機動力不足造成自動變速器不易升檔。用VAG1552故障閱讀儀檢測發動機電控系統，調到故障碼00561，含義為混合氣調整超過極限。將故障碼清除后，重新起動發動機，調得的故障碼依舊?？赡芤鸫斯收洗a的原因有：一是燃油壓力低;二是空氣流量傳感器信號數值有誤;三是炭罐電磁閥卡死;四是排氣系統泄漏;五是噴油器堵塞。經檢查，燃油壓力正常，進、排氣系統無漏氣現象。做完發動機免拆清洗和節氣門體清洗后，清除故障碼，再次起動發動機，未調到故障碼。讀取數據流，各項數據正常。然后進行路試，故障現象仍然存在，沒有好轉跡象。

Automatic transmission fault analysis: The technician checked the automatic transmission fluid (ATF) and found that the oil level was normal without any odor. Based on the phenomenon, it is determined that insufficient engine power is causing the automatic transmission to be difficult to upshift. Use the VAG1552 fault reading device to check the engine electronic control system and set it to fault code 00561, which means that the mixture adjustment exceeds the limit. After clearing the fault code and restarting the engine, the obtained fault code remains the same. The possible causes of this fault code are: firstly, low fuel pressure; Secondly, there is an error in the signal value of the air flow sensor; Thirdly, the carbon canister solenoid valve is stuck; Fourthly, there is a leakage in the exhaust system; The fifth issue is fuel injector blockage. After inspection, the fuel pressure is normal and there is no leakage in the intake and exhaust systems. After completing the engine non disassembly cleaning and throttle body cleaning, clear the fault code and restart the engine, but do not adjust to the fault code. Read data stream, all data is normal. Then a road test was conducted, and the fault still existed without any signs of improvement.

自動變速箱維修過程：技師用VAG1552故障閱讀儀進入自動變速器系統進行故障查詢，未發現故障碼。隨后進行路試，讀取自動變速器控制系統的數據流，發現自動變速器在每個檔位都能正常工作，只是換檔點太遲，換檔沖擊大。當檢查ATF溫度時，故障閱讀儀顯示該溫度在153℃-165℃間波動，明顯高于正常值。

Automatic transmission maintenance process: The technician used the VAG1552 fault reader to enter the automatic transmission system for fault inquiry, but no fault codes were found. Subsequently, a road test was conducted to read the data stream of the automatic transmission control system, and it was found that the automatic transmission could work normally in every gear, but the shift point was too late and the shift shock was significant. When checking the ATF temperature, the fault reading instrument shows that the temperature fluctuates between 153 ℃ and 165 ℃, significantly higher than the normal value.

該車選用的自動變速器型號為01N，當ATF溫度高于148℃時，自動變速器會自動切換至下一個低檔位，以加大自動變速油的流動，降低油溫，避免自動變速器因過熱而損壞。而ATF溫度過高時，自動變速器電控單元并不記憶故障碼，只有通過讀取數據流才能發現。

The automatic transmission model used in this car is 01N. When the ATF temperature exceeds 148 ℃, the automatic transmission will automatically shift to the next lower gear to increase the flow of automatic transmission oil, lower the oil temperature, and avoid damage to the automatic transmission due to overheating. When the ATF temperature is too high, the automatic transmission electronic control unit does not remember the fault code and can only detect it by reading the data stream.

將該車用舉升機升起，檢查自動變速器油底殼，感覺其溫度并沒有像故障閱讀儀顯示的那么高。將發動機熄火靜置2h后，再次用VAG1552故障閱讀儀檢測ATF溫度，發現還是160℃，而此時ATF的實際溫度只有40℃左右。懷疑ATF溫度傳感器出現故障。將自動變速器油底殼拆下，拆下自動變速器扁平線束，用萬用表測量ATF溫度傳感器的電阻，檢查其阻值是否隨溫度變化而正常變化。經檢測，ATF溫度傳感器正常(20℃時，其電阻值約為0.25MΩ;60℃時，約為49kΩ;120℃時，約為7.5kΩ)。當用萬用表直接從扁平線束的連接器相應端子處檢測ATF溫度傳感器電阻時，發現該數值始終不隨溫度變化而變化，而是固定在2kΩ不變。據此判斷扁平線束損壞。

Raise the car with a lift and check the automatic transmission oil pan. It feels that the temperature is not as high as displayed on the fault reading instrument. After turning off the engine and letting it stand for 2 hours, the VAG1552 fault reading instrument was used again to check the ATF temperature, and it was found that it was still 160 ℃, while the actual ATF temperature at this time was only about 40 ℃. Suspect that the ATF temperature sensor is malfunctioning. Remove the oil pan of the automatic transmission, remove the flat wire harness of the automatic transmission, measure the resistance of the ATF temperature sensor with a multimeter, and check if its resistance changes normally with temperature. After testing, the ATF temperature sensor is normal (at 20 ℃, its resistance value is about 0.25M Ω; at 60 ℃, it is about 49k Ω; at 120 ℃, it is about 7.5k Ω). When using a multimeter to directly detect the resistance of the ATF temperature sensor from the corresponding terminal of the flat wire harness connector, it was found that the value did not change with temperature, but remained fixed at 2k Ω. Based on this, it is determined that the flat wire harness is damaged.
