Automatic transmission detection is divided into basic detection, stall detection, gear detection, hydraulic detection and road detection. The core of automatic transmission maintenance is to realize automatic shift. The so-called automatic shift means that the driver controls the accelerator pedal (accelerator pedal) according to the needs of the driving process during the driving process of the car. The automatic transmission can automatically shift into different gears according to the engine load and the operating conditions of the car. The purpose is to determine the technical status of the transmission by testing, find out the cause and location of the fault, and take corresponding measures to eliminate the fault.

1常規檢測

1 routine test

自動變速箱故障主要是由于自動變速箱維護不當所致。自動變速箱維修是相對于手動變速箱而出現的一種能夠自動根據汽車車速和發動機轉速來進行自動換擋操縱的變速裝置。目前汽車自動變速箱常見的有四種型式，分別是液力自動變速箱、機械無級自動變速箱(、電控機械自動變速箱和雙離合自動變速箱。因此，首先要對自動變速箱進行基本的檢測和調整，這樣不僅可以解決由于維修不當而引起的一些故障，而且可以為進一步的故障診斷提供有用的信息。

The failure of automatic transmission is mainly caused by improper maintenance of automatic transmission. Automatic transmission maintenance is a kind of transmission device which can automatically shift according to vehicle speed and engine speed. At present, there are four types of automatic transmission, namely hydraulic automatic transmission, mechanical stepless automatic transmission, electronic mechanical automatic transmission and double clutch automatic transmission. Therefore, first of all, the automatic transmission should be tested and adjusted, which can not only solve some faults caused by improper maintenance, but also provide useful information for further fault diagnosis.

(1)檢測發動機怠速

(1) Detect engine idle speed

發動機怠速，達到正常水溫后，自動變速箱置于“N”位置時，發動機的怠速是否在規定的范圍內。如果怠速過低，當變速器放置在“R”、“D”、“2”或“1”位置時，會引起汽車振動，影響座椅的舒適性，嚴重地使發動機熄火。如果怠速過高，就會產生換擋沖擊。

When the engine idles and reaches the normal water temperature, whether the idle speed of the engine is within the specified range when the automatic transmission is placed in the "n" position. If the idle speed is too low, when the transmission is placed in "R", "d", "2" or "1" position, it will cause vehicle vibration, affect the comfort of the seat, and seriously make the engine flameout. If the idle speed is too high, there will be shift impact.

(2)檢測節流閥電纜

(2) Throttle cable detection valve

在自動變速箱中，節流電纜連接到發動機上的節氣門。通過改變油門位移，將發動機油門開度信號轉換為油門壓力信號。油門張力線的檢測主要是檢查反映發動機負荷的油門開度，以及是否準確地反映了自動變速箱中的油門。

In an automatic transmission, the throttle cable is connected to the throttle valve on the engine. By changing the throttle displacement, the engine throttle opening signal is converted into the throttle pressure signal. The detection of throttle tension line is mainly to check whether the throttle opening reflects the engine load and whether it accurately reflects the throttle in the automatic transmission.

(3)齒輪選擇機構的檢測

(3) Detection of gear selection mechanism

驅動器操作齒輪選擇，控制閥實現換擋。如果選擇器控制閥發生故障，自動變速箱將無法正常工作。

The driver operates the gear selection, and the control valve realizes shifting. If the selector control valve fails, the automatic transmission will not function properly.

首先，觀察齒輪選擇機構的傳動桿是否變形或干涉，以及接頭是否固定良好。然后將選擇手柄懸掛在每個齒輪上，并利用手柄的感覺來判斷選擇機構是否工作正常。例如，手柄在進入每個齒輪時是否靈活，進入齒輪后手柄是否處于正確的位置，等等。

Firstly, observe whether the transmission rod of gear selection mechanism is deformed or interfered, and whether the joint is fixed well. Then hang the selection handle on each gear, and use the feeling of the handle to judge whether the selection mechanism works normally. For example, whether the handle is flexible when entering each gear, whether the handle is in the correct position after entering the gear, etc.

檢測中性啟動開關，以確定發動機是否僅在變速器換檔手柄處于“N”或“P”位置時才能啟動，以及是否僅在齒輪選擇手柄位于“R”位置時才打開倒車燈，以便打開倒車燈。

The neutral start switch is tested to determine if the engine can only be started when the transmission shift handle is in the "n" or "P" position, and whether the backup lights are turned on only when the gear selection handle is in the "R" position in order to turn on the backup lights.

檢測超速控制開關，查看自動變速箱超速是否正常。

Check the overspeed control switch to check whether the automatic transmission is normal.

在安裝強制下檔開關并打開開關時，檢測強制齒輪開關，以查看傳感器電路中某些導線的連接是否良好，節氣門開度是否正常。

When installing the forced downshift switch and opening the switch, check the forcing gear switch to see if some wires in the sensor circuit are connected well and whether the throttle opening is normal.
